Additional Features
Compatible With
Most Video Conference Applications
Users are free to use the any video conferencing applications on desktop, including Zoom, Microsoft Teams, Google Meet, etc.
USB Plug-and-Play Connectivity
With no special software, training, or maintenance required,
connecting to a video teaching has never been easier.
Realistic sound quality
The speaker can bring realistic sound, so that everyone can feel full, excellent sound
Specification
Dual Camera
• Ultra wide-angle camera
- 8M pixels
- f/1.8 Aperture
- 5x digital zoom / EPTZ
- 120° wide-angle field of view
- 4K capture resolution
• Telephoto camera
- 6x hybrid zoom (3x optical, 2x digital)
- 52° field of view
- 1080p capture resolution
• Intelligence Feature
- Auto Framing
- Speaker Tracking
• Video encoding:
H.265/H.264/MJPEG/YUV
• Camera indicator
Audio
• Support full-duplex conversations,
acoustic echo cancellation and
background noise suppression
• Mute / Unmute controls
• Stereo microphone:
- 8 MEMS microphone array
- 16.7ft / 6m pickup range
- 120 Hz–16 kHz frequency response
• Speaker:
- 100Hz-20KHz Frequency response
- Output = 90 dB @ 0.5m
Interfaces
• 1x USB2.0 Type-C port
• Power connector
• Bluetooth control key
• Kensington security lock
• Bluetooth 4.2
System Requirements
• Supported operating systems
- Windows 7, 8.1, 10, 11
- MacOS 10.15 or Higher
- Chrome OS™
- Android™ 6.0 or Higher
• Supports standard audio and video
device drivers
- UAC 1.0 Audio
- UVC 1.1/1.5 Video
- HID 1.11
Application Compatibility
• Compatible with any application that
supports standard USB audio and video
drivers, including but not limited to:
- Microsoft Teams / MTR
- Zoom / Zoom Rooms
- GoToMeeting / GoToRoom
- BlueJeans
- Google Meet
- Cisco Webex
- Amazon Chime
- Slack
• Compatible with Clickshare CX-20/
CX-30/CX-50
Package Contents
• DoubleView N120U
• Remote control with 2 AAA batteries
• Power adapter
• 5m USB2.0 cable (Type-C to Type-A)
• Wall mount kit
• Setup sheet
Size and Weight
• Size (H x W x D):
78 x 503 x 53 (MM)
3.07 x 19.8 x 2.09 (Inches)
• Weight:
3.09 lbs 49.4 oz (1.4 kg)
Remote Control
• Remote control for Camera/
Speaker/Microphone functions
• 33-foot (10m) range remote
control
Power Requirements
• 12VDC/2A@100~240VAC,
50/60Hz
Environmental
• Working temperature:
32-104°F (0-40°C)
• Relative humidity:
5-95%, noncondensing
• Storage temperature:
-13-160°F (-25-70°C)
Warranty Information
• 2-year limited hardware
